6” Borehole Pump-6SP17 Series Deep Well Submersible Pump -

6SP17 series

≋ 6SP Submersible Deep Well Pump

∿ We provide a wide range of deep well submersible pumps from 2” to 10” which are designed for transferring water from wells, ponds, lakes and cisterns.

◍ 6SP series are suitable for wells over φ150mm

✓ Reliable Structure for Continuous Water Delivery

★ Stainless Steel Shaft • Efficient Motor • Built to Last

Product Description

6SP deep well submersible pump is used to pump water from drilled deep wells, borehole wells, ponds, and lakes. Ideal for pressure boosters, firefighting systems, elevated and cistern tanks filling, water fountains, industrial and farming water supply, and agricultural irrigation.

Operation Coditions

Maximum fluid temperature up to +50℃

Maximum sand content:0.25%

Minimum well diameter:6″

Features

Rewindable motor

Single-phase:220-240V/50Hz

Three-phase:380-415V/50Hz

①Direct start (1 cable)

②Star-delta start (2 cables)

Equip with start control box or digital auto-control box

Components	Material
Delivery casing	AISI304 SS
Suction lantern	AISI304 SS
Diffuser	AISI304 SS
Impeller	AISI 304 SS
Shaft	AISI431 SS
Shaft coupling	AISI304 SS
Wear ring	Rubber
Motor external casing	AISI 304 SS
Top chock	Cast-iron ASTM NO.30
Bottom support	Cast-iron ASTM NO.30
Seal	NBR Graphite-SIC/TC
Shaft	AISI 304 SS-ASTM5140
